Features
- 416cc, 8.5bhp, 4stroke Japanese (Kubota)diesel engine
- Decompression mechanism interlocked with starter circuit.
- Attractive twin head lights with halogen lamps.
- Styled instrument panel.
- Large & attractive side indicators.
- Triple vortex combustion system.
- Foot operated diaphragm clutch.
- Oil-air cooling.
- Glow plug provided in engine.
- Low chassis overhang.
Technical Specifications
Engine |
Type |
4 stroke, single cylinder, compression ignition |
Capacity |
416.6 cc |
Max Power |
8.5 bhp( 6.25 kW) @ 3600 rpm |
Max Torque |
20 Nm @ 2400 rpm |
Suspension |
Front |
Hydraulic brakes with tandem mater cylinder & auto adjuster |
Rear |
Hydraulic brakes with tandem mater cylinder & auto adjuster |
Tyres |
Front |
4.5x10,8PR |
Rear |
4.5x10,8PR |
Electrical |
System Voltage |
12V DC |
Head Lamp |
35/35 W |
Fuel Tank |
Material |
Plastic |
Capacity |
8 lit |
Dimensions |
Overall height |
1880 mm |
Overall length |
3090 mm |
Overall Width |
1300mm |
Wheelbase |
2025 mm |
Min Ground Clearance |
170 mm |
Weights |
GVW |
876 |
|
|
|
|
